Creating Virtual Machine Using Powershell

Creating Virtual Machine Using PowerShell

The Virtual Machine is an OS that is installed on software that imitates dedicated hardware.The End user has same experience on VM as they would have on dedicated hardware.

 Now we are going to write a PowerShell Script that will Create a Virtual Machine for us

We are  going to create a Windows Virtual Machine Windows Server 2016. Putting All  togather

# Silently Logging to Azure Portal
Select-AzureRmProfile -Path "login.json"
# Variables Declaration and Definition Area
#-------------------------------------------------------------------------
$RG="Osgroup"
$LOCATION="South Central US"
$VMNAME="osgroup" $NICName="osgroupNIC"
$PublciIPName="PIPOSGRP"
$DnsName="osgroupdns"
$VNetName="OsgroupVNET"
$SubNetName="OsgroupSubnet1"
$NSGNAME="OsgroupNSG"
#------------------------------------------------------------------------
# Storing The Credentials for Azure Login to Vms
$CRED= Get-Credential
# NSG
$Rule1=New-AzureRmNetworkSecurityRuleConfig -Name "web-rule" -Description "allow all" `
-Access Allow -Protocol Tcp -Direction Inbound -Priority 100 -SourceAddressPrefix Internet `
-SourcePortRange "*" -DestinationAddressPrefix * -DestinationPortRange *


$NSG=New-AzureRmNetworkSecurityGroup -Name $NSGNAME -ResourceGroupName $RG -Location $LOCATION `
-SecurityRules $Rule1


# Pubic IP
$PIP=New-AzureRmPublicIpAddress -Name $PublciIPName -ResourceGroupName $RG -DomainNameLabel $DnsName `
-Location $LOCATION -AllocationMethod Static

# NIC
$vnet = Get-AzureRmVirtualNetwork -ResourceGroupName $RG -Name $VNetName

$NIC=New-AzureRmNetworkInterface -Name $NICName -ResourceGroupName $RG -Location $LOCATION `
-SubnetId $vnet.Subnets[0].id -PublicIpAddressId $PIP.Id -NetworkSecurityGroupId $NSG.Id



$VMCONFIG=New-AzureRmVMConfig -VMName $VMNAME -VMSize Standard_DS2 |`
Set-AzureRmVMOperatingSystem -Windows -ComputerName $VMNAME -Credential $CRED |`
Set-AzureRmVMSourceImage -PublisherName MicrosoftWindowsServer -Offer WindowsServer -Skus 2016-Datacenter -Version latest |`
Add-AzureRmVMNetworkInterface -Id $NIC.Id

New-AzureRmVM -ResourceGroupName $RG -Location $LOCATION -VM $VMCONFIG


Write-host"Have a nice time ahead!!! Thank you "
